WeatherDuino_Probe_pcb.png ‎(246 × 579 pixels, file size: 28 KB, MIME type: image/png)

First draft (Single layer) PCB design for the WeatherDuino Remote Probe

File history

Click on a date/time to view the file as it appeared at that time.

Date/TimeThumbnailDimensionsUserComment
current02:21, 1 November 2013Thumbnail for version as of 02:21, 1 November 2013246 × 579 (28 KB)Fludizz (talk | contribs)Made the PCB even smaller and connected the unused wires to GND to avoid possible interference.
00:59, 3 July 2013Thumbnail for version as of 00:59, 3 July 2013324 × 633 (41 KB)Fludizz (talk | contribs)First draft (Single layer) PCB design for the WeatherDuino Remote Probe
